Fiberglass surface tissue for epoxy resin is mainly used for surface treatment of GRE products.

Fiberglass surface tissue for epoxy resin is mainly used for surface treatment of GRE products. It has the

characteristics of high tensile strength, fast penetration speed of epoxy resin, no bubble and less resin

consumption. The fiberglass surface tissues for epoxy resin are not loose, not broken and with high

efficiency in the epoxy resin during the penetration process. It is suitable for winding, hand lay-up and

molding manufacturing techniques.

fiberglass surface tissue for epoxy FRP pipe epoxy

Product Code	Unit Weight	LOI	MD Tensile Strength	Moisture Content	Epoxy resin Penetrating time
	g/m2	%	N/50mm	%	S
F-BM-30WE	30	≤10	≥50	≤0.5	≤20 (2 layer)
F-BM-50WE	50	≤10	≥120	≤0.5	≤30 (2 layer)
F-BM-70WE	70	≤10	≥180	≤0.5	≤30 (1 layer)
F-BM-100 WE	100	≤10	≥220	≤0.5	≤30 (1 layer)
Testing Basis	ISO3374	ISO1887	ISO3342	ISO3344	EN 14118
Paper core diameter: 76/152mm

Product Code	Unit Weight	LOI	MD Tensile Strength	Moisture Content	Epoxy resin Penetrating time
	g/m2	%	N/50mm	%	S
F-BM-30WE	30	≤10	≥50	≤0.5	≤20 (2 layer)
F-BM-50WE	50	≤10	≥120	≤0.5	≤30 (2 layer)
F-BM-70WE	70	≤10	≥180	≤0.5	≤30 (1 layer)
F-BM-100 WE	100	≤10	≥220	≤0.5	≤30 (1 layer)
Testing Basis	ISO3374	ISO1887	ISO3342	ISO3344	EN 14118
Paper core diameter: 76/152mm
